Image Sensor

1/3" HDIS

1/3" SONY

1/3" SHARP

1/3" SONY

Horizontal Resolution

700TVL, With IR-CUT

960H, 800TVL,
With IR-CUT

500TVL, Low Illumination

600TVL, Low Illumination

960H, 700TVL,
Low Illumination

650TVL,
Low Illumination, DWDR, OSD, DNR

960H, 700TVL,
Low Illumination, DWDR, OSD, DNR, UTC Effio-E

Pixels

976(H)×496(V)

PAL:500(H)×582(V) NTSC:510(H)x492(V)

PAL:752(H)×582(V) NTSC:768(H)×494(V)

NTSC:976(H)×494(V) PAL:976(H)x582(V)

NTSC:768(H)×494V) PAL:752(H)x582(V)

NTSC:976(H)×494(V) PAL:976(H)x582(V)

TV System

PAL/NTSC

IR Series Distance

20 Meters

IR LED

￠5X24 PCS

Lens

Board Lens 3.6mm/F2.0

Sync System

Internal, Negative sync

Usable Illumination

0.01Lux /F1.2

0.001 Lux/F1.2

S/N Ratio

≥46dB (AGC OFF)

≥48dB(AGC OFF)

≥52dB (AGC OFF)

Gamma Correction

0.45

Video Out

1Vpp, 75Ω

Scanning System

2:1 interface

Electronic Shutter Time

NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s

Operation  Temperature

-10℃ ~ +50℃ RH95% Max

Storage  Temperature

-30~+60℃ RH95% MAX

White Balance

Auto

Power Source

DC12V(+/-10%)/350mA

Dimension

193(W) x67(H) x70(D)

Package

Weight

450g
