Image Sensor

1/3" SONY

1/3" SHARP

1/3" SONY

1/3" HDIS

Horizontal Resolution

1.3 Megapixel Sensor, 720P, Low Illumination, OSD, IR-CUT, 3D NR, Digital Zoom

960H, 700TVL, Low Illumination, Real WDR, OSD, 3D NR, UTC Effio-P

960H, 700TVL, Low Illumination, Super WDR, 3D NR, Demist, SLR, Sense-up, UTC, OSD (Auto Iris with ICR add USD5)

960H, 700TVL, Low Illumination, DWDR, OSD, DNR, UTC Effio-E

650TVL, Low Illumination, DWDR, OSD, DNR

960H, 700TVL, Low Illumination

600TVL, Low Illumination

500TVL, Low Illumination

960H, 800TVL, With IR-CUT

700TVL,
With IR-CUT

Pixels

1309(H)×1049(V)

NTSC:976(H)×494(V) PAL:976(H)x582(V)

NTSC:976(H)×494(V) PAL:976(H)x582(V)

NTSC:768(H)×494V) PAL:752(H)x582(V)

NTSC:976(H)×494(V) PAL:976(H)x582(V)

PAL:752(H)×582(V) NTSC:768(H)×494(V)

PAL:500(H)×582(V) NTSC:510(H)x492(V)

976(H)×496(V)

TV System

PAL/NTSC

IR LED

￠5X42PCS

IR Series Distance

40M

Lens

2.8-12mm Manual Zoom Lens

Sync System

Internal, Negative sync

Usable Illumination

0.01Lux /F1.2

0.001 Lux/F1.2

0.01Lux /F1.2

0.001Lux /F1.2

S/N Ratio

≥50dB (AGC OFF)

≥52dB (AGC OFF)

≥48dB (AGC OFF)

≥46dB (AGC OFF)

Gamma Correction

0.45

Video Out

1Vpp, 75Ω

Scanning System

2:1 interface

Electronic Shutter Time

NTSC: 1/60s~1/100, 000s, PAL: 1/50s~1/100,000s

Operation  Temperature

-10℃~+50℃ RH95% Max

Storage  Temperature

-30~+60℃ RH95% MAX

White Balance

Auto

Power Source

DC12V (+/-10%)/500mA

Dimension

275(W) x 91(H) x 80(D)

Package

Weight

1400g
