3ch car video recorder
Product Features
1.120-degree wide angle video, image restoration effect is good,
no distortion
2. Built-in microphone/speaker
3. Support high capacity TF card (recommended to use high speed
card
4. Loop video, seamless coverage video
5. Bluetooth hands-free calling to improve driving safety
6. GPS function is optional
7. G-sensor function
8. Acceleration impact files automatic protection function, does
not overwrite crucial files
9. Large screen displays, surface design of the rear-view mirror,
upgraded Visual angle
10. Recording
while parking
Switching of cameras
Dual camera——Right camera ——Left camera——Dual camera
Parameters
|
Mode
|
Menu
|
Menu setting
|
|
Video mode
|
Video
|
MP
|
VGA/720P
|
|
RT
|
1min/2min/5min/OFF
|
|
video setting
|
Bright
|
Auto / Sunlight / Fluorescence/ Cloudysky / Tungsten
|
|
Exposal
|
-3/-2/-1/0/1/2/3
|
|
Color
|
Null / Black and white / Negative / Ancient / light blue
|
|
Auto detect
|
OFF/ON
|
|
Water Mark
|
OFF/ON
|
|
Audio
|
OFF/ON
|
|
Auto record
|
OFF/ON/Charge video
|
|
Language
|
中文简体/中文繁體/English/Deutsch/日本言語/ Français/
Português/한국어/ Italiano/Русский
|
|
Frequency
|
50Hz/60Hz
|
|
Shutdown time
|
1min/3min/5min/OFF
|
|
Key tone
|
OFF/ON
|
|
Readjustment volume
|
11/12/13/14/15
|
|
Auto backbright off
|
1min/3min/5min/off
|
|
G-sensor
|
High/Middle/low/off
|
|
TV OUT
|
PAL /NTSC
|
|
GPS correction time
|
OFF/ON
|
|
Park video
|
OFF/ON
|
|
Date set
|
YY/MM/DD
|
|
format
|
Yes/on
|
|
system info
|
Current version of the machine
|
|
Default set
|
Yes/on
|
|
Photo mode
|
|
MP
|
1M/2M/3M/5M/8M/12M
|
|
Photo setting
|
Bright
|
Auto / Sunlight / Fluorescence/ Cloudysky / Tungsten
|
|
Exposal
|
-3/-2/-1/0/1/2/3
|
|
Color
|
Null / Black and white / Negative / Ancient / light blue
|
|
Water mark
|
OFF/ON
|
|
Language
|
中文简体/中文繁體/English/Deutsch/日本言語/ Français/
Português/한국어/ Italiano/Русский
|
|
Frequency
|
50Hz/60Hz
|
|
Key tone
|
OFF/ON
|
|
Readjustment volume
|
11/12/13/14/15
|
|
Date set
|
YY/MM/DD
|
|
Format
|
Yes/no
|
|
System info
|
Current version of the machine
|
|
Default set
|
Yes/no
|
|
LCD Screen
|
4.3 inch TFT LCD(480*272)
|
|
COMS SENSOR
|
1.2MP
|
|
Lens
|
120 degree wide-angle lens
|
|
Minimum LUX
|
1LUX
|
|
Video resolution
|
Left lens 1280*720/640*480
Right Lens 1280*720/640*480
Dual lens 1920*720/1280*480
|
|
Video format
|
MOV
|
|
Video compression format
|
H.264
|
|
Frames
|
The front lens 1280*720 30fps/640*480 30fps
The rear lens 720*480 25fps
|
|
Image resolution
|
Dual lens 1M/2M/3M/
Single lens 1M/2M/3M/5M/8M/12M
|
|
Image format
|
JPG
|
|
Cycle recording
|
1min/2mins/5mins/OFF
|
|
AV IN with reversing function
|
Support（Optional）
|
|
GPS
|
Optional
|
|
G-sensor
|
Support
|
|
One key to turn on/off recording
|
Support
|
|
One key save
|
Support
|
|
Bluetooth
|
Optional
|
|
IR remote control
|
Optional
|
|
Parking while recording（10mins parking of 5fps）
|
Support
|
|
Memory card type
|
TF card
|
|
Memory card capacity
|
Maximum support 32G
|
|
USB port
|
USB2.0
|
|
Vehicle charging source interface
|
DC12V，600MA DC5V(USB接口） 1000MA
|
|
Frequency
|
50HZ/60HZ
|
|
Battery
|
3.7V/630mAH lithium polymer battery
|
|
Microphone/Speaker
|
support
|
|
Language
|
Simplified Chinese/Traditional
Chinese/English/Russian/Japanese/Korean
|
|
Weight
|
360G
|
|
Dimension
|
278*96*49MM
|
Structure
1. Reset key
2. TF card slot
3. Microphone
4. ON/OFF key
5. Light 6.
Menu key
7. Mode key
8. Built-in speaker key
9. Bluetooth key 10.
Up key
11. Down key 12.
Bluetooth light
13. OK key
14. AV OUT
15. USB/GPS 16.
DC 12V
17. Lens 18.
LCD
Installation
Package
